Electrical Specifications
Key Features:
-IFOV (spatial resolution): 5.6 mRad -Resolution: 80x60 (4,800 pixels) -Field of view: 19.5 °H x 26 °V -Wireless connectivity: No -Focus system: Fixed focus 46 cm (18 in) and beyond -Ruggedized display: 3.5 inch diagonal (portrait format) -Rugged, ergonomic design for one-handed use: Yes -Thermal sensitivity (NETD): = 0.15 °C at 30 °C target temp (150 mK) -Temperature measurement range (not calibrated below -10 °C): -20 °C to +250 °C (-4 °F to +482 °F) -Level and span: Smooth auto and manual scaling -Fast auto toggle between manual and auto modes: Yes -Fast auto-rescale in manual mode: Yes -Minimum span (in manual mode): 2.5 °C -Minimum span (in auto mode): 5 °C -Built-in digital camera (visible light): 2 megapixel industrial performance -Frame rate: 9 Hz only
Data Storage and Image Capture:
-Extensive SD memory system: :Removable 4 GB SD memory card and 8 GB wireless SD card (where available) :Direct download via USB-to-PC connection -Image capture, review, save mechanism:One-handed image capture, review, and save capability -File formats image: :Non-radiometric (.bmp) or (.jpeg) or fully-radiometric (.is2) :No analysis software required for non-radiometric (.bmp, .jpg) files -Memory review: Thumbnail view navigation and review selection -Software: SmartView® software, and SmartView® Mobile app—full analysis and reporting software -Export file formats with SmartView® software: BMP, DIB, GIF, JPE, JFIF, JPEG, JPG, PNG, TIF, and TIFF
Battery:
-Batteries (field-replaceable, rechargeable): One lithium ion smart battery pack with five-segment LED display to show charge level -Battery life: Four+ hours continuous use per battery pack (assumes 50% brightness of LCD and average usage) -Battery charge time: 2.5 hours to full charge -AC battery charging system: In-imager charging. AC mains adapters included in 9 Hz versions. Optional two-bay AC battery charger (110 V AC to 220 V AC, 50/60 Hz) or optional 12 V automotive charging adapter. -AC operation: AC operation with included power supply (110 V AC to 220 V AC, 50/60 Hz). AC mains adapters included. -Power saving: User selectable sleep and power off modes
Temperature Measurement:
-Accuracy: ± 2 °C or 2% (at 25 °C nominal, whichever is greater) -On-screen emissivity correction: Yes (both number and table) -On-screen reflected background temperature compensation: Yes
Color Palettes:
Standard palettes: 3: Ironbow, blue-red, grayscale
|
General Specifications
-Infrared spectral band: 9 µm to 15 µm (long wave) -Operating temperature: -10 °C to +50 °C (14 °F to 122 °F) -Storage temperature: -20 °C to +50 °C (-4 °F to 122 °F) -Relative humidity: 10% to 95%, non-condensing -Center-point temperature measurement: Yes -Safety standards: CSA (US and CAN): C22.2 No. 61010-1-04, UL: UL STD 61010-1 (2nd Edition), ISA: 82.02.01 -Electromagnetic compatibility: EN 61326-1:2006 IEC 61326-1:2005 -C Tick: IEC/EN 61326-1 -US FCC: EN61326-1; FCC Part 5 -Vibration: 2G, IEC 68-2-6 -Shock: 25G, IEC 68-2-29 -Drop: Engineered to withstand 2 meter (6.5 feet) drop -Size (H x W x L): 28.4 cm x 8.6 cm x 13.5 cm (11.2 in x 3.4 in x 5.3 in) -Weight (battery included): 0.726 kg (1.6 lb) -Enclosure rating: IP54 (protected against dust, limited ingress; protection against water spray from all directions) -Warranty: Two-years (standard), extended warranties are available -Recommended calibration cycle: Two-years (assumes normal operation and normal aging) -Supported languages: Czech, Dutch, English, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, and Turkish
|
Brand SKU
FLK-TI90-9HZ
|
Rashi Part SKU
FLK-TI90-9HZ
|
Warranty
2 Years
|
