Fluke - FI-7000 AP - Fiber Optic Power Meters and Fault Locators
Model No :
FI-7000 AP
Part Code :


The FI-7000 FiberInspector Pro is a fiber optic inspection scope that allows you to inspect and certify fiber optic connector. This fiber optic inspection scope provides automated PASS/FAIL certification take the guess work out of fiber inspection so anyone can be a fiber expert.

- Fiber Inspection Certification
- Graphical indication of Problem Areas
- Store End-face Images
- Built on the Versiv Platform
- Versiv’s ProjX™ System
- Taptive™ User Interface
- LinkWare™ Live Test Results Management Service
- LinkWare™ Management Software
- PASS/FAIL Fiber End-face Grading

General Specifications
- Weight Mainframe with module and battery: 3 lbs, 5 oz (1.28 kg)
- Dimensions Mainframe with module and battery: 2.625 in x 5.25 in x 11.0 in ( 6.67 cm x 13.33 cm x 27.94 cm)
- Battery Lithium ion battery pack, 7.2 volts
- Battery life Eleven hour with Inspection probe attached
- Charge Time:
• Tester Off Four hours to charge from 10% to 90% capacity
• Tester On Six hours to charge from 10% to 90% capacity with the tester on
