Netrack
Outdoor Cabinet-LFloor Mount Racks-FMOD
Model No :
FMOD
Part Code :
FMOD

Overview

Floor mount Racks for Outdoor Available from 6RU to 27RU Variants with 600 & 800 Width and 600~800 Depth configurations.

Standard for Racks will be fully welded frame with integrated side panel and Associated Front & Back Metal Door with 3 Point lock & Key and provision to mount racks on Floor.

Fan mounting provision can be on sides or top with canopy with filter unit to meet IP 56 (Ingress protection) requirements

Features
-Conforms to DIN 41494 or Equivalent EIA /ISO/ EN/ CEA Standard
-Adjustable mounting depth
-Conforms to IEC 60529 or Equivalent IS/ EN/ Standards for Ingress Protection
-State-of-the-art manufacturing methods provide the best product quality and fastest delivery in the industry
-Grounding & Bonding Options
-100% assured compatibility with all equipments conforming to DIN 41494 (General industrial standard for equipments)
-Special Dual Coat Powder coated finish with seven-tank pretreatment process meeting ASTM standard to Meet Harsh Out door Requirement.
-2 No Adjustable, 19” verticals with Punched 10 mm Square Hole and Universal 12.7mm-15.875mm-15.875mm alternating hole pattern offers greater mounting flexibility, maximizes usable mounting space.
